Muffle Furnace With Flap Door, 1200°C

• Optimal temperature uniformity of +/- 5K with closed fresh air inlet in empty workspace
• Dual shell housing made of textured stainless steel sheets with additional fan cooling for low surface temperature
• Only fiber materials are used which are not classified as carcinogenic according to TRGS 905, class 1 or 2
• Ceramic heating plates with integral heating elements which are safeguarded and easy to replace
• Adjustable air inlet integrated in door
• Exhaust air outlet in rear wall of furnace
• Solid state relays provide for low-noise operation
• NTLog Basic for Nabertherm controller: recording of process data with USB-flash drive
• Defined application within the constraints of the operating instructions
• Very short delivery times for standard furnaces and spare parts

Additional equipment

• Chimney, chimney with fan or catalytic converter
• Over-temperature limit controller with adjustable cutout temperature for thermal protection
• Protective gas connection to purge with non-flammable gases
• Manual or automatic gas supply system
• Port for thermocouple in the rear wall or in the furnace door
• Process control and documentation via VCD software package for monitoring, documentation and control

Note: The UK standard socket/plug is 13 amps. This equates to 2.9 kw. Higher than 3 kw would mean 16 amp sockets or higher.
