Hypersil GOLD™ C18 Selectivity HPLC Columns
Use these endcapped, ultrapure, silica-based columns to generate exceptional peak shape and resolution for HPLC and LC/MS analyses using generic gradients
Have Questions?
Change view
| Catalog Number | Length (Metric) | Diameter (Metric) | Particle Size | Unit Size |
|---|---|---|---|---|
| 25005-254630 also known as HYP25005-254630 | 250 mm | 4.6 mm | 5 μm | EA |
| 25003-052130 also known as HYP25003-052130 | 50 mm | 2.1 mm | 3 μm | Each |
| 25003-102130 also known as 25003-102130B | 100 mm | 2.1 mm | 3 μm | Each |
| 25003-103030 | 100 mm | 3 mm | 3 μm | Each |
| 25003-104630 | 100 mm | 4.6 mm | 3 μm | Each |
| 25003-152130 also known as HYP25003-152130 | 150 mm | 2.1 mm | 3 μm | Each |
| 25003-153030 | 150 mm | 3 mm | 3 μm | Each |
| 25003-154630 | 150 mm | 4.6 mm | 3 μm | Each |
| 25003-014001 | 10 mm | 4 mm | 3 μm | Each |
| 25002-052130 also known as 25002-052130U | 50 mm | 2.1 mm | 1.9 μm | Each |
| 25002-102130 | 100 mm | 2.1 mm | 1.9 μm | Each |
| 25002-152130 also known as HYP25002-152130 | 150 mm | 2.1 mm | 1.9 μm | Each |
| HYP25002-152130 | 150 mm | 2.1 mm | 1.9 μm | EA |
| 25003-012101 also known as 25003-012101U | 10 mm | 2.1 mm | 3 μm | Each |
| 25003-013001 | 10 mm | 3 mm | 3 μm | Each |
| 25005-014001 also known as 25005-014001U | 10 mm | 4 mm | 5 μm | Each |
| HYP25005-014001 | 10 mm | 4 mm | 5 μm | PK |
| 25005-052130 also known as HYP25005-052130 | 50 mm | 2.1 mm | 5 μm | Each |
| HYP25005-052130 | 50 mm | 2.1 mm | 5 μm | EA |
| 25005-102130 | 100 mm | 2.1 mm | 5 μm | Each |
| HYP25005-102130 | 100 mm | 2.1 mm | 5 μm | EA |
| 25005-104630 also known as 25005-104630B | 100 mm | 4.6 mm | 5 μm | Each |
| 25005-152130 also known as 25005-152130B | 150 mm | 2.1 mm | 5 μm | Each |
| 25005-153030 | 150 mm | 3 mm | 5 μm | Each |
| 25005-154030 also known as HYP25005-154030 | 150 mm | 4 mm | 5 μm | Each |
| 25005-154630 | 150 mm | 4.6 mm | 5 μm | EA |
| HYP25005-154630 | 150 mm | 4.6 mm | 5 μm | EA |
| 25005-253030 | 250 mm | 3 mm | 5 μm | Each |
| 25005-254030 | 250 mm | 4 mm | 5 μm | Each |
| HYP25005-254630 | 250 mm | 4.6 mm | 5 μm | EA |
Catalog number 25005-254630
also known as HYP25005-254630
View Price:Sign InSign in to see your account pricing. Need an account? Register with us today.
Length (Metric):
250 mm
Diameter (Metric):
4.6 mm
Particle Size:
5 μm
Unit Size:
EA
Achieve exceptional peak shape and resolution for your HPLC and LC/MS applications with Thermo Scientific™ Hypersil GOLD™ HPLC columns. These endcapped, ultrapure, silica-based columns deliver significant reduction in peak tailing using generic gradients with C18 selectivity. With their excellent resolution, efficiency, and sensitivity, Hypersil GOLD columns give you confidence in the accuracy and quality of your analytical data.
Novel Bonding
- Proprietary derivatization and endcapping
- C18 (USP L1) selectivity
pH Stability
- Robust performance at high pH
- Excellent column stability at low pH
Flexible Formats
- Javelin HTS columns for high-throughput screening
- Semi-preparative columns with 12 μm particles available
About the Hypersil GOLD Family of HPLC Columns
Meet the challenges of modern chromatography with state-of-the-art columns that provide outstanding performance and consistent separations. Twelve different column chemistries are available so you can optimize separations and maximize productivity. Get outstanding peak shapes in reversed phase, ion exchange, HILIC, or normal phase chromatography.
- Excellent peak symmetry
- Narrow peaks for outstanding efficiency
- Enhanced sensitivity and improved resolution
- Exceptional reproducibility for reliable chromatography, column after column
- Solutions for high-throughput screening
- 1.9, 3, and 5 μm particle sizes for all your separation needs
Limited warranty period: Subject to all warranty requirements and exclusions set out in our Terms and Conditions of Sale, this product is warranted from the date we ship the product and for ninety (90) days thereafter. Disclaimer to internal research use restriction: Any restrictions on the purchaser to utilize the product(s) for internal research purposes only does not apply to the product(s) on the web pages associated with this statement.
Specifications
Column FormatAnalytical Column
Diameter (Metric)4.6 mm
Length (Metric)250 mm
Max. Pressure5800 psi (400 bar)
Particle Size5 μm
pH1 to 11
Pore Size175 Å
QuantityEach
Surface Area220 m²/g
Temperature60°C
USP TypeL1
Stationary PhaseC18 Selectivity
Product LineHypersil GOLD
Packing MaterialSpherical, Fully Porous, Ultrapure Silica
Carbon Load11%
Column TypeReversed Phase
EndcappedYes
PhaseReversed Phase
Unit SizeEA
